Specification
| LH series of standard parameter table (160 S) | ||
| ITEMS | Unit | Specification |
| Clamping Force | KN | 1600 |
| Opening stroke | mm | 380 |
| Die thickness(Min--Max) | mm | 200～550 |
| Space between tie bars | mm | 460*460 |
| Ejector stroke | mm | 85 |
| Ejector force | KN | 108 |
| Injection position（0 as center） | mm | 0，-140 |
| Injection force（intensification) | KN | 270 |
| Injection stroke | mm | 340 |
| Plunger diameter | mm | ￠40 ￠50 ￠60 |
| lnjection weight(aluminum) | Kg | 1.8 |
| Casting pressure (intensification) | MPa | 214/137/95 |
| Max. casting area(40Mpa) | CM2 | 400 |
| Injection plunger penetration | mm | 110 |
| Diameter of pressure chamber flange | mm | 110 |
| Height of pressure chamber flange | mm | 10 |
| Max.working pressure | MPa | 14 |
| Motor power | Kw | 11 |
| Dimensions (L*W*H) | m | 5.5*1.5*2.35 |
| Machine lifting reference weight | T | 6 |
| Oil tank capacity | L | 520 |
will not be changed without notice)
ABOUT US
Bengbu Longhua Die Casting Machine Co.,Lid is a company based in Bengbu City,Anhui Province,
China.It specializes in the manufacturing of die casting machines and related equipment.
Established in 1982,Longhua Die Casting Machine Co.,Ltd has been involved in the die casting
industry for several decades.The company focuses on research,development,production,and
sales of various types of die casting machines.The company's product range covers cold chamber
die-casting machines,die-casting manipulators,industrial robots and peripheral equipment of
die-casting machines to meet the needs of different customers.
FAQ：
1. Who are we?
We are based in Anhui, China, Longhua was founded in 1950 and has specialized in the R&D and manufacturing of die-casting machines since 1982.We now have more than 44 years of history in R&D and casting.To date, our products have been exported to more than 43 countries.
2. How can we guarantee quality?
Always final Inspection before shipment;
3. What can you buy from us?
Die casting machines, die casting machine robots, die casting machine parts and consumables, moulds, melting furnaces and other peripheral equipment.
4. Why should you buy from us not from other suppliers?
Longhua Die Casting Machine has more than 44 years of production experience, and cooperate with the Chinese Academy of Science and Technology, you know that China's space shuttles are cooperating with the Chinese Academy of Science and Technology.
5. What services can we provide?
Accepted Delivery Terms: FOB/EXW;
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,Credit Card,Cash;
Language Spoken:English,Chinese;
