Features of cold chamber die casting machine:
1. High pressure and high precision: The cold chamber die casting machine can provide a high-pressure casting
process to ensure that the die-casting parts have good compactness and high-precision dimensional control,
making the product quality more stable.
2. Suitable for large parts: Cold chamber die casting machines are usually suitable for the production of large
die castings, such as automobile engine casings, aerospace engine parts, etc., which can meet the production
needs of products with high size and structure requirements.
3. Reduce pores and shrinkage porosity: Since the cold chamber die casting machine uses a closed die-casting
chamber, defects such as gas pores and material shrinkage can be effectively reduced during the casting process,
improving the compactness and internal quality of the product.
4. High temperature control: The cold chamber die casting machine can precisely control the temperature of the
die casting chamber to ensure that the molten metal maintains a suitable temperature when injected into the mold,
improving the surface quality and forming performance of the product.
5. Reliable injection system: The cold chamber die casting machine is equipped with a reliable metal injection
system, which can ensure the stability and uniformity of the metal liquid during the injection process, improving
product consistency and quality stability.
6. Rapid cooling system: Cold chamber die casting machines are usually equipped with a rapid cooling system,
which can speed up the cooling speed of castings, reduce production cycles, and improve production efficiency.
7. Energy saving and environmental protection: The cold chamber die casting machine can effectively control
energy consumption during the production process, reduce waste generation, meet environmental protection
requirements, and improve the sustainability of production.
8. Automation control: Cold chamber die casting machines are usually equipped with advanced automation
control systems, which can achieve fully automated production, reduce manual intervention, and improve
the stability and consistency of the production line.
Specification
| LH series of standard parameter table (160 G) | ||
| ITEMS | Unit | Specification |
| Clamping Force | KN | 1600 |
| Opening stroke | mm | 360 |
| Die thickness(Min--Max) | mm | 200～550 |
| Space between tie bars | mm | 440*440 |
| Ejector stroke | mm | 80 |
| Ejector force | KN | 100 |
| Injection position（0 as center） | mm | 0 ，- 140 |
| Injection force（intensification) | KN | 180 |
| Injection stroke | mm | 320 |
| Plunger diameter | mm | ￠40 ￠50 ￠60 |
| lnjection weight(aluminum) | Kg | 1.5 |
| Casting pressure (intensification) | MPa | 143/92/64 |
| Max. casting area(40Mpa) | CM2 | 400 |
| Injection plunger penetration | mm | 120 |
| Diameter of pressure chamber flange | mm | 110 |
| Height of pressure chamber flange | mm | 10 |
| Max.working pressure | MPa | 12 |
| Motor power | Kw | 11 |
| Dimensions (L*W*H) | m | 5.2*1.5*2.05 |
| Machine lifting reference weight | T | 5.2 |
| Oil tank capacity | L | 500 |
(Due to the continuous progress of science and technology,the picture,parameter configuration,etc,
will not be changed without notice)
Features of factory-direct die-casting machines include:
1. Original factory guarantee: If you purchase a die-casting machine directly from the manufacturer, you can
get direct guarantee and service support from the original factory to ensure the reliability of product quality
and after-sales service.
2. Product customization: Factory direct sales can usually provide more flexible customized services,
customizing the production of die-casting machines according to customer needs to meet the specific
requirements of different customers.
3. Price advantage: You may enjoy a price advantage by purchasing a die-casting machine directly from the
manufacturer, eliminating the profit of the middleman and obtaining a more competitive price.
4. Controllable product quality: Direct sales from manufacturers can better control product quality, ensure that
products meet standard requirements, and reduce quality fluctuations that may be caused by intermediate links.
5. Timely after-sales service: Direct purchase of die-casting machines can provide timely after-sales service
support. Manufacturers can respond to customer needs more quickly and provide after-sales technical
support and maintenance services.
6. Professional technical support: Factory direct sales can usually provide professional technical support,
including equipment operation training, maintenance guidance, etc., to help customers better use and
maintain die-casting machine equipment.
7. Reputation guarantee: Factory direct sales can provide more reliable products and services, establish
good reputation and reputation, and provide customers with more reliable cooperation guarantee.
ABOUT US
Bengbu Longhua Die Casting Machine Co.,Lid is a company based in Bengbu City,Anhui Province,China.It
specializes in the manufacturing of die casting machines and related equipment.
Established in 1982,Longhua Die Casting Machine Co.,Ltd has been involved in the die casting industry for
several decades.The company focuses on research,development,production,and sales of various types of
die casting machines.The company's product range covers cold chamber die-casting machines,die-casting
manipulators,industrial robots and peripheral equipment of die-casting machines to meet the needs of
different customers.
