  • Application case | inverter used in energy-saving reconstruction of die casting machine
    February 16,2022.

    Application case | inverter used in energy-saving reconstruction of die casting machine

    01. Brief introduction of die casting industry At present, the vast majority of die casting machines belong to hydraulic transmission die casting machines, the power of hydraulic transmission system is provided by the motor driven oil pump. In the process of die casting cycle changes, die casting machine in different processes need different flow and pressure, must rely on flow valve and pressure valve to adjust the different flow and pressure required by different processes. And when the load change is relatively large, because the output power of the quantitative pump can not be adjusted, so the excess energy can only be consumed in the baffle, oil leakage, oil temperature rise, which also aggravates the wear of various valves, and causes high oil temperature, excessive noise of the motor, and shortened mechanical life and other phenomena. And usually in the design of the capacity of the motor is much higher than the actual need, there is a "big horse car" phenomenon, resulting in a lot of waste of electric energy. Therefore, it is of great significance to promote the application of frequency converter in die casting machine to reduce energy waste. 02.die casting machine hydraulic system principle overview (1) Overview of working principle of die casting machine Hydraulic injection machine is a kind of typical equipment periodic duty, in a complete working cycle (processes) can be roughly divided into clamping, for soup, and shoot, core-pulling, open mode, thimble, cooling, accumulator and so on several stages, each stage is through the oil pump motor pump out of the hydraulic oil into each cylinder drive transmission mechanism through a series of actions, Each stage requires different pressures and flows. For hydraulic system, each stage requirements for pressure, flow rate of each different, and the oil pump motor power is based on the maximum load allocation in the process of operation, and the die casting machine of a work cycle, only high pressure clamping and then shoot stage work load is bigger, the other work stage generally small, during the process of cooling load is almost zero. For oil pump motor, the process of die casting machine is driven by changes in the load state, quantitative pump in hydraulic system, the oil pump motor at a constant speed to provide a constant flow, and the working pressure and flow required size is depends on the pressure proportional valve and flow proportional valve to regulate, by adjusting the pressure or flow proportional valve opening to control pressure or flow rate. The excess hydraulic oil flows back through the relief valve. This process is called high pressure closure, and the energy loss caused by it is generally around 50%. (2)Overview of energy saving reform principle of die casting machine According to the working principle of die casting machine, high pressure cut-off is the waste of energy consumption of oil pump motor. My company production of die casting machine is special use of this ch...
    Read More
  • Application of high pressure casting technology and new technology of die casting machine
    February 6,2022.

    Application of high pressure casting technology and new technology of die casting machine

    The essence of high pressure die casting (die casting for short) is a method that makes liquid or semi-liquid metal fill the cavity of die casting mold (die casting mold) at a high speed under high pressure, and forms and solidifies under pressure to obtain the casting. 1.High pressure casting process 1.1 High pressure casting plane layout At present, the general die-casting island will consider the following configuration; Die-casting machine with vacuum, heat preservation furnace is equipped with quantitative casting system, do and product with the type of spraying system, shorten the spraying time, the robot to take parts, slag bag, code cutting and other work, the last cutting to the gate system; The die-casting island can also be upgraded for automated cleaning under high volume conditions. 1.2 Application of CAE simulation software CAE analysis is more and more widely used in die casting industry, represented by PROCAST, MAGMA, flow-3D, etc. According to the calculation results of filling flow and velocity distribution, the simulation can accurately predict the defects such as enrolling, inclusion and bad filling, which greatly improves the yield and saves a very objective cost. It is a very useful tool to quickly and scientifically design the whole casting system (gate, sprue and overflow tank, etc.) for die casting. Optimize casting process parameters, reduce the number of mold testing, reduce casting cost, improve product quality. CAE software was used for general analysis of filling, solidification, porosity distribution and velocity distribution reports (as shown in Figure 2). 1.3 Application of vacuum die casting With the continuous supply of product quality requirements, the use of vacuum to solve the problem of filling and air tightness of castings has been well developed, and vacuum valve is generally used, the most commonly used vacuum valve has the following two structures. Figure 3 is the schematic diagram of the vacuum valve. Like ordinary die casting process, after aluminum water enters the chamber, vacuumization begins to start. Then, when the die casting machine starts at high speed, the kinetic energy of aluminum water is relied on to touch the spring plate of the vacuum valve. When using a mechanical vacuum valve, it is generally closed when preheating the mold. When the preheating is complete, the vacuum valve can be used only when the high speed and pressurization is started. Mechanical vacuum valve has the advantages of simple use, but the processing accuracy of vacuum valve is high, and the cost of vacuum valve is relatively high. Figure 4 is the schematic diagram of the hydraulic vacuum valve. The principle of the mechanical vacuum valve is the same. When the punch starts, the vacuum starts, but the principle of closing the vacuum valve is different. When the hydraulic vacuum valve is generally started at high speed, the type is sent to the hydraulic system of the...
    Read More
  • Ways to improve the service life of die casting
    2022-01-18

    Ways to improve the service life of die casting

    Die casting mold is the core equipment of die casting production, and its service life directly affects product quality, production efficiency and enterprise cost. The durability of die casting mold mainly depends on four key factors: high-quality die steel selection, scientific mold design, optimized processing technology, and standardized operation and maintenance. High-quality die steel material is the foundation of long mold service life. The purity, uniformity and low impurity of die steel determine critical performances including plasticity, toughness, thermal conductivity, high-temperature yield strength and backfire resistance. Materials with excellent high-temperature strength and creep strength effectively prevent crack generation, while high toughness slows crack propagation. Low thermal expansion coefficient and high thermal conductivity reduce thermal stress and thermal deformation, greatly improving the stability of die casting mold. Reasonable mold design plays a vital role in extending mold life. The mold structure shall meet the requirements of die casting technology, machining and heat treatment. Optimized gating system layout provides a reliable foundation for overall mold design. Sufficient mold wall thickness ensures structural strength and stiffness to avoid deformation and stress concentration cracks under high pressure. Properly designed cooling channels keep the mold working at a constant temperature and prevent thermal damage. Optimized processing technology and standardized daily operation and maintenance further reduce mold wear. Strict full-process control effectively extends mold service life, helping die casting enterprises achieve stable, efficient and low-cost production.
    Read More
  • Die casting operation specification
    January 6,2022.

    Die casting operation specification

    Die casting machine operation specification 1. Pre shift preparation 1.1 die casting workers must wear labor protection articles as required at work, including work clothes, work shoes and work hats. It is strictly prohibited to wear vests, shorts and shirtless. 1.2 the die casting worker must arrive at the post 20 minutes in advance for pre job preparation, including: View shift change records Prepare class II tools and inspection tools required for production Check the product quality of the last shift, this shift and other shifts 1.3 15 minutes before shift handover, the team leader shall gather the team members to hold a pre shift meeting, including: The shift leader shall arrange and adjust the work on duty The monitor shall convey the company's decision The monitor introduces various problems existing in the work time, reminds employees and puts forward requirements. 2. Production preparation verification 2.1 before production, it must be verified according to production preparation verification, including process verification: Check whether the actual process on site is consistent with the process card Input and check the process without input item by item 3. Machine start 3.1 before starting the machine tool, the aluminum die casting machine tool must be comprehensively checked to ensure that the die-casting machine tool is in normal state. 3.2 before starting the machine tool, manually lubricate it for 3 times before starting it. 3.3 jog to start the machine tool and observe the operation of the machine tool. If there is any abnormality, stop the machine immediately. 3.4 after the machine tool is started, the cooling water shall be turned on to prevent the oil temperature from rising. 3.5 in case of machine tool failure or alarm signal, immediately check the cause and report for repair. It is strictly prohibited to work with machine tool failure. 4. Mold installation for pressure casting machine
    Read More
  • Problems easily ignored in die casting production site
    January 6,2022.

    Problems easily ignored in die casting production site

    Bengbu Longhua Die‑Casting Machine Co., Ltd. has released key technical guidance on frequently‑overlooked faults during production with a horizontal cold‑chamber die‑casting machine, helping foundry operators avoid costly downtime and premature damage to core die‑casting equipment. Improper connection, misalignment and insufficient daily maintenance are major hidden risks that shorten the service life of large‑tonnage die‑casting machine components. Many workshop failures stem from the poor fit of injection‑related assemblies,the situation is as follows: 1.The injection plug rod, injection rod and molten‑cup bore must remain strictly co‑axial with zero‑loose connections.  2.Operators need to replace cushion blocks regularly, keep the ejector‑rod joint tight, ensure unobstructed cooling water and fully lubricate the injection head.  3.Bent ejector rods or misaligned injection heads and molten cups are forbidden during operation. Thousands of repeated injection shocks gradually compress the cushion‑block length, creating gaps at the split‑wrap‑clamp joint. Off‑axis operation will trigger a series of typical defects:  1.frequent bending and fracture of ejector rods; 2.stuck injection heads with short service life; 3.unilateral wear on injection‑head; 4.molten cup and gate sleeve; 5.aluminum splashing; 6.large flashing on material handles; 7.unstable casting quality; Most technicians misjudge these symptoms as poor injection‑head quality. Longhua provides two simple on‑site inspection methods for die‑casting machinery. Operators can measure circumferential clearance between injection rod and molten‑cup after manual injection, with 0.2 mm center deviation set as the tolerance limit. Repeated switching between injection and middle‑position can detect up‑and‑down runout, which signals rod deformation. Once misalignment occurs, factories should replace damaged parts, match cushion‑block gaps within 0.1 mm and carry out 24‑hour routine spot‑checks on clamp screws and joints. Different connection structures, including horseshoe‑floating connectors widely used on domestic die‑casting machine, demand enhanced daily maintenance to achieve stable long‑term production.
    Read More
  • Industrial robots bring vitality to the automotive industry
    December 30,2021.

    Industrial robots bring vitality to the automotive industry

    Introduction: before industrial robots brought vitality to the automobile industry, the application scope of industrial robot technology in the manufacturing industry in the world has become wider and wider. It has been extended from traditional manufacturing industry to other manufacturing industries, and then to various non manufacturing industries, but the automobile industry is still the main application field of industrial robots. It is understood that% of industrial robots in the United States are used in automobile production; Used in the automotive industry worldwide. Before industrial robots brought vitality to the automotive industry, the application scope of industrial robot technology in the manufacturing industry has become wider and wider in the world. It has been extended from traditional manufacturing industry to other manufacturing industries, and then to various non manufacturing industries. However, the automotive industry is still the main application field of industrial robots. It is understood that% of industrial robots in the United States are used in automobile production; Industrial robots used in the automotive industry in the world have reached 37% of the total consumption, and industrial robots used in automotive parts account for about 24%. In China, the initial application of industrial robot is in automobile and construction machinery industry, mainly used for spraying and welding of automobile and construction machinery. At present, due to the backwardness of robot technology and R & D, industrial robots are mainly used in manufacturing and less in non manufacturing. According to statistics, in recent years, more than half of the industrial robots produced by domestic manufacturers are provided to the automotive industry. It can be seen that the development of automobile industry is one of the driving forces for the growth of industrial robots in China in recent years. At the same time, in the "notice on organizing and implementing the development of intelligent manufacturing equipment" issued by the national development and Reform Commission, the Ministry of finance, the Ministry of industry and information technology and other ministries and commissions, according to the current situation of the development of intelligent manufacturing equipment in China, the "special" will focus on supporting the research and development of intelligent complete sets of equipment and key intelligent components required in automobile manufacturing and other fields, In the near future, it will focus on promoting the application of industrial robots and key intelligent components, such as robot automobile welding automation production line related to automobile, digital workshop and intelligent logistics system. Among the new national major technical equipment projects with demand as the traction, process as the guide, emphasis on user participation and finally aiming at the industrialization and transformation results, there ar...
    Read More
  • Comparative advantages of industrial robot and traditional die casting manipulator
    December 30,2021.

    Comparative advantages of industrial robot and traditional die casting manipulator

    Introduction: save the release agent: the amount of robot spray and artificial spray release agent is the same. It saves more than half of the dosage of the release agent, and the spray position is more accurate than that of the traditional sprayer. It can improve the quality of the product. The copper tube sprays, because of the air pressure reason, the copper tube will be changed after a few hours, and it needs to be adjusted manually, while the robot fixed the spray. High accuracy and many stored programs: can the robot be right.  Save release agent: The dosage of the robot spray and the artificial spray release agent is the same, which saves more than half of the releasing agent dosage than the traditional sprayer The spray position is accurate: it can improve the quality of products. The copper tube sprays, because of the air pressure reason, the copper tube will be changed after a few hours, and it needs to be adjusted manually. Storage program: robot can store more than 99 spray programs for different molds, write programs, and then tune them out for use. Life expectancy: after 4 years of conventional sprayers, there are many problems, such as slideway and guideway wear, and the robot will live longer than 8 years under proper operation. Robot flexibility is high: the traditional sprayer can only spray, and when the robot changes the fixture, it can also be used for picking or other purposes. Program changes are simple: The robot has a hand-held programmer for easy operation.  The fault rate is low: the traditional sprayer will be repaired several times on average, but the robot will hardly fail at the correct operation.
    Read More
  • Congratulations to our company for winning the certificate of the standing director unit of the Anhui Chamber of Commerce for Import and Export
    2021-12-29

    Congratulations to our company for winning the certificate of the standing director unit of the Anhui Chamber of Commerce for Import and Export

    Congratulations to our company for winning the certificate of the standing director unit of the Anhui Chamber of Commerce for Import and Export
    Read More
first page 21 22 23 24 25 26 27 28 29 30 last page

A total of 37 pages
